PV ZK906 three-split junction box with fully potted design concept uses high-end integrated chips. The electrical connection performance is stable and reliable. This product has six groups of busbar output ports, using welding method, suitable for high efficiency mono and poly-silicon solar modules.
| Project | Performance Index | |
| Rated Current | 20/25/30/35 | A |
| Rated Voltage | 1500 | V DC |
| Cable size range | 4 | mm² |
| Temperature range | -40 ~ +85 | ℃ |
| Width of Copper Ribbons | Up to 8 | mm |
| Protection level | IP68 | |
| Safety Class | Class II | |
| Flame Resistance | V-0 | |
| Waterproof Structure | Potting sealant | |
| Amount of glue | Appr. 20ml | |
| Connection Method | Soldering | |
| Insulation Material | PPE+PS, PA | |
| Contact Material | Copper tin plating | |
| Optional Connector | PV-KST4-EVO2/II, QC4.10, PV-KBT4-EVO2/II, PV-ZKC2, PV-ZKC4 | |
