PV LT2 Connector
Product Standard: IEC62852:2014 CE
Rated Voltage: 1500V DC
Protection Degree: IP68
Product Standard: IEC62852:2014 CE
Rated Voltage: 1500V DC
Protection Degree: IP68
| Material | Pure Copper + Stainless Steel 301 |
| Plating Requirement | Nickel underplating: 1–3μm; Surface tin plating: 3–5μm |
| Contact resistance | ≤0.4mΩ |
| Pin resistance | ≤0.21mΩ |
| Socket resistance | ≤0.19mΩ |
| Resistance after 100 insertion/withdrawal cycles | R1≤1.25R0 |
| Insertion force | ≤50N |
| Withdrawal force | ≥10N |
| Salt spray test | After 48 hours of salt spray testing, no corrosion on the surface. |
